UM49B Microphone

A faithful sonic reproduction of the vintage M49B, our latest UM-Series microphone has the same signature smooth and detailed highs, exceptional midrange clarity, and rounded deep low-end as the original. Its large, rich and balanced tone ideally suited for vocals, a continuously adjustable pattern switch ensures the UM49B can also perform as a truly versatile studio all-rounder.

Handbuilt to order in Switzerland, the UM49B is designed to be one of the highest quality microphones available today. The components used are identical to our RS Series, and the UM49B can at any time be traded in towards the RS4 (M49B version).



Downloads
UM49B Owner's manual

Price
CHF 2'285,00

Quantity:
Add To Cart


+ Product Features

• M49B inspired, fixed bias circuit
• Thiersch Blueline capsule
• Haufe BV11 transformer
• NOS 5703 vacuum tube
• Sommer Octave cable
• Custom Rycote shockmount
• 10-year warranty
• Handbuilt in Switzerland

+ Specifications

• Type: Cond. pressure gradient
• Capsule: M7, PVC diaphragm
• Patterns: Multi incl. O-C-8
• Freq. Range: 20Hz to 20kHz
• Max SPL: ≈ 130dB
• Noise: 16 dB, A-weighted
• Dimensions: 245 x ø44mm
• Weight: 790gms

+ Options & Settings

• RS 6120 PSU (optional)
• Redline capsule (optional)
• RS4 trade-in (optional)
• Plate Supply: 120V
• Plate Current: ≈ 0,73mA
• Heater Voltage: -6,30V
• Heater Current: 200mA
• Impedance: 200Ω
